Front Frame

Front Frame Worksheet

Worksheet can be completed using the form below or downloaded for printed use.

Vehicle Information

Car Year/Model:

Tire Size:

Wheel Size:

Wheelbase (Full Frames Only):

Measurements (in inches)

A - Wheel Mount to Outside Tire:

B - Outside Tire to Inner Fender:

C - Wheel Mount to Inner Fender:

D - Inner Fender to Inner Fender:

E - Wheel Mount to Wheel Mount:

F - Crossmember to Wheel Mount:

Steel Spindles with 8319-XX brakes

Steel Spindles with 8324-XX brakes

Aluminum Uprights with 8377-XX brakes

Aluminum Uprights with 8378-XX brakes

G - Crossmember Width:

Customer Information

Customer Name:

After printing to PDF, please email the completed worksheet to: sales@cachassisworks.com
